Type

Speed
(Gbps)

Conductor

Insulation

Drain

Size

Impedance
(Ω)

Intra Skew
(ps/m max)

IL@13.28Ghz
(dB/m Nom)

IL@14Ghz
(dB/m Nom)

IL@16Ghz
(dB/m Nom)

IL@28Ghz
(dB/m Nom)

IL@30Ghz
(dB/m Nom)

AWG

Material

Material

ID/mm

AWG

Material

L(mm)

W（mm）

PCIE5.0

32

29

SC

FEP+PTFE

0.55

34

TC

1.11

1.75

85±5

8

4.7

4.9

5.1

7.8

8.4

30

SC

FEP+PTFE

0.49

34

TC

1.01

1.52

8

5.6

5.7

6.0

8.7

9.4

32

SC

FEP+PTFE

0.40

34

TC

0.92

1.42

8

7.0

7.2

7.6

11.5

12.0

34

SC

FEP+PTFE

0.30

34

TC

0.82

1.35

8

8.5

8.9

9.5

14.3

14.8
