Type |
Speed (Gbps) |
Conductor |
Insulation |
Drain |
Size |
Impedance |
Intra Skew |
IL@8Ghz |
IL@12Ghz |
IL@16Ghz |
||||
|
AWG |
Material |
Material |
ID/mm |
AWG |
Material |
L(mm) |
W（mm） |
|||||||
|
PCIE4.0 |
16 |
30 |
SC |
FEP |
0.65 |
32 |
TC |
0.79 |
1.84 |
85±5 |
10 |
5.7 |
7.1 |
8.9 |
|
32 |
SC |
FEP |
0.48 |
34 |
TC |
0.62 |
1.42 |
10 |
6.8 |
8.4 |
11.8 |
|||
|
34 |
SC |
FEP |
0.40 |
34 |
TC |
0.54 |
1.26 |
10 |
8.0 |
10.0 |
13.8 |
|||
